| Part Status | Активный |
| Circuit | SPDT |
| Switch Function | On-Mom |
| Current Rating (Amps) | 10A (AC), 6A (DC) |
| Voltage Rating – AC | 125 V |
| Voltage Rating – DC | 30 V |
| Actuator Type | Roller Plunger |
| Mounting Type | Chassis Mount |
| Termination Style | Screw Terminal |
| Ingress Protection | IP67 – Dust Tight, Waterproo |
| Features | – |
| Operating Force | 700gf |
| Release Force | 170gf |
| operating Position | 1.866″ (47.4mm) |
| Pretravel | 0.060″ (1.5mm) |
| Differential Travel | 0.008″ (0.2mm) |
| Overtravel | 0.098″ (2.5mm) |
| Operating Temperature | -10°C~ 80*C |
| Electrical Life | 500,000 Cycles |
| Mechanical Life | 10,000,000 Cycles |
