AXIOMTEK SBC81206 Материнская плата

Спецификация материнской платы

• Audio: HD Codec audio as MIC-in/Line-in/Line-out/speaker-out with audio kit AX93242 (optional)
• Battery: Lithium 3V/220 mAH
• BIOS: Phoenix-Award
• Chipset: Intel GMA 950 graphics Core
• CPU: LGA775 socket for Intel Core2 Duo/Pentium 4/ Pentium/Celeron processors with FSB 533/800 MHz
• Display Interface: 1x VGA
• Display Memory Size: Intel DVMT 3.0 compliant
• Ethernet: 2 ports as 10/100/1000Mbps support Wake-on-LAN; RPL/PXE Boot ROM with Realtek RTL8111B
• Expansion Interface: 4x 32-bit PCI bus masters; 16-bit ISA bus
• Hardware Monitoring: Detect CPU/system temperature, voltage and fan speed
• MIO: 1x IDE; PATA-100; 1x FDD; 1x PS/2 keyboard; 1x PS/2 mouse; 1x LPT; with SPP/EPP/ECP supported; 1x RS-232 (COM 1); 1x RS-232/422/485 (COM 2)
• Operation Humidity: 10% ~ 95% relative humidity, non-condensing
• Processor: Intel Pentium 4
• SATA: 4x SATA-300; with RAID 0/1/10/5 (optional with ICH7R)
• Size: 338x 122 mm
• SMBus: System Management Bus for advanced monitoring/control
• SSD: IDE DoM
• System Chipset: Intel 945GC + ICH7/7R
• System Memory: 2x 240-pin DIMM supports DDR2-400/533/667 max up to 2GB
• Temperature: 0°C ~ +60°C (32°F ~ 140°F), operation
