Технические характеристики
| System Chipset | VIA VT82C496G |
|---|---|
| Ethernet Chipset | UMC UM9008 |
| Form Factor | ISA |
| Audio | N/A |
| Battery | Lithium battery |
| BIOS | AWARD® 1Mbit |
| Board Type | Half Size |
| Cache Memory | 128 KB SRAM |
| Chipset | Asiliant® (C & T) 65550 VIA® VT82C496G |
| Controller | UMC UM9008 (PCA-6145B only) built-in 8 k x 16 SRAM |
| CPU | Supports Intel® 80486 DX/DX2/DX4, AMD 80486 DX2/DX4 |
| Размеры | 185 x 122 mm (7.3” x 4.8”) 0.27 kg (weight of total package) |
| Display Interface | N/A |
| Expansion Interface | 1 x 16-bit ISA slot, 1x PC/104 connector |
| Gross Weight | N/A |
| I/O Chipset | 1 x EIDE, 1 x FDD, 1 x K/B, 1 x Mouse, 1 x RS-232/422/485, 1 x RS-232, 1 x LPT |
| IDE Interface | PC/104, ISA |
| Input | 1 x RJ-45 |
| IR Interface | N/A |
| LCD Controller | N/A |
| LCD Interface | 16-bit TTL for Mono/STN/TFT LCD |
| Memory | 1 MB |
| Operating Humidity | 0% ~ 90% relative humidity, non-condensing |
| Operating Temperature | 0 ~ 60° C (32 ~ 140° F), operation |
| Power Consumption | Max : 5 V @ 3 A Typical : 5 V @ 1.8 A (w/ AMD 5×86-P75, 16 MB DRAM) |
| Power Management | APM 1.1 |
| Power Supply | +5 V ± 5% |
| Resolutions | CRT mode: 1024 x 768 @ 8 bpp (non-interlaced), 800 x 600 @ 8 bpp 640 x 480 @ 8 bpp LCD mode: 640 x 480 @ 16 bpp |
| Speed | 10/100Base-T |
| SSD | DiskOnChip® |
| System Memory | FPM/EDO SIMM x 1, Max. 32 MB |
| System Monitor | NE-1000 and NE-2000 |
| TV-out | N/A |
| USB | N/A |
| Wake On LAN | Build-in system BIOS (optional) |
| Watchdog Timer | 1 ~ 62 sec., System reset or IRQ15 |
