Спецификация материнской платы
Технические характеристики
| Audio | N/A |
|---|---|
| Battery | Lithium 3 V/196 mAH |
| BIOS | AWARD® 256 kbit Flash BIOS |
| Cache Memory | 64 KB on the CPU |
| Chipset | VIA VT8606 “TwisterT” integrated ProSavage4 2D/3D/Video Accelerator VIA VT8606 “TwisterT”+VT82C686B |
| Controller | Intel 82551/82559 (PCA-6774F-00A1, PCA-6774F-02A1) Intel 82540 (PCA-6774FG-00A1) |
| CPU | Supports FC-PGA/FC-PGA2 Socket 370, Celeron/ Pentium III CPU, up to 1.26 GHz Pentium III with 512 KB (Does not support PPGA CPU) |
| Размеры | 185 x 122 mm (7.3″ x 4.8″) 0.27 kg (weight of total package) |
| Display Interface | N/A |
| Expansion Interface | 1 x 16-bit ISA slot |
| Gross Weight | N/A |
| I/O Chipset | 2 x EIDE , 1 x FDD, 1 x K/B, 1 x Mouse, 1 x RS-232/422/485, 1 x RS-232, 1 x LPT |
| IDE Interface | I/O daughter board connectors, ISA |
| Input | 1 x RJ-45 |
| IR Interface | N/A |
| LCD Controller | 2-Channel (2 x 18-bit) LVDS interface |
| LCD Interface | 36-bit TTL |
| Memory | 8/16/32 MB frame buffer using system memory |
| Operating Humidity | 0% ~ 90% relative humidity |
| Operating Temperature | 0 ~ 60° C (32 ~ 140° F), operation |
| Power Consumption | Max. : 6.18 A @ +5 V, 0.22 A @ +12 V Typical : 5.5 A @ +5 V(w/128MB SDRAM, Pentium III 1.0GHz) 0.17A @ +12 V(w/128 MB SDRAM, Pentium III 1.0 GHz) |
| Power Management | ACPI, APM1.2 |
| Power Supply | +5 V, +12 V ± 5% |
| Resolutions | CRT Mode: 1280 x 1024 @ 16 bpp (60 Hz), 1024 x 768 @ 16 bpp (85 Hz) 800 x 600 @ 16 bpp (60 Hz), LCD Mode: 1280 x 1024 @ 16 bpp (60 Hz) 1024 x 768 @ 16 bpp (60 Hz) 1280 x 1024 @ 32 bpp |
| Speed | 10/100Base-T, 10/100/1000Base-T |
| SSD | Supports CompactFlash® Card typeI/II |
| System Memory | 1 x SDRAM DIMM, Max. 512 MB |
| System Monitor | IEEE 802.3 z/ab (1000Base-T) or IEEE 802.3u (100Base-T) protocol compatible |
| TV-out | N/A |
| USB | 4 x USB ports, USB 1.1 compliant |
| Wake On LAN | (optional when using Intel 82559 LAN chip) |
| Watchdog Timer | 1 ~ 62 sec, System reset or IRQ11 |
Features
- Four AGP graphics for high performance
- Giga LAN/Second Lan support
- Socket 370 supports up to 1.26 GHz Intel Pentium III with 512 KB
- Supports TFT and DSTN LCD, LVDS
- Supports up to 133 MHz FSB
