Модуль ПЛК Omron ZEN-10C1DT-D-V2

Type

Smart relay

Display type

LCD display

Power supply voltage

12…24VDC

Power consumption/Power loss

2W

Program language

Ladder

Number of digital inputs (No.DI)

4 (6)

Rated input voltage

12…24VDC

Digital input type

Sink/source

Number of digital outputs (No.DO)

4

Digital output type

Транзистор

Number of analog inputs (No.AI)

2

Analog input range

0…10VDC

Analog input resolution

1/100

Expandable modular

Да

Connection method

Screw terminals

Mounting method

DIN Rail (Track) mounting, Surface mounting

Operation ambience

Indoor

Ambient temperature

0…55°C

Ambient humidity

10…90%

Approx. weight

300g

Overall width

70mm

Overall height

94.7mm

Overall depth

56mm

Degree of protection

IP20

Representative standard

UL, CE

Standard accessories

Нет

Separately accessories

DIN track: PFP-100N, DIN track: PFP-100N2, End plate : PFP-M, DIN track: PFP-50N, Battery unit: ZEN-BAT01, Connecting cable: ZEN-CIF01, Power supply unit: ZEN-PA03024, Expansion I/O unit: ZEN-8E1AR, Expansion I/O unit: ZEN-8E1DR, Expansion I/O unit: ZEN-8E1DRT, Memory cassette: ZEN-ME01
