Материнская плата Advantech AIMB-766VG-00A1E

Name: Материнская плата Advantech AIMB-766VG-00A1E
Brand: Адвантех
SKU: AIMB-766VG-00A1E
Price: 204 USD
Availability: instock

$ долларов США204.00

Материнская плата Advantech AIMB-766 REV.A1 AIMB-766VG AIMB-766VG-00A1E

Артикул: AIMB-766VG-00A1E Категория: использовал

Спецификация материнской платы

Form Factor	АТХ
Ethernet Chipset	Intel 82566DM
System Chipset	Intel Q35
BIOS	AMI 32Mbit SPI
Board Type	АТХ
Chipset	Intel Q35+ICH9 DO
Размеры	304.8 x 244 mm (12″ x 9.6″)
EIDE	ATA 100/66/33 Mode; 1(max. 2 devices) Channel
Environment	Operating Temp. 0 ~ 55° C (32 ~ 140° F), depends on CPU’s speed and cooler solution; Non-Operating Temp. -20 ~ 70° C (-4 ~ 158° F)
Ethernet	10/100/1000 Base-T interface; G-LAN1: Intel 82566DM, G-LAN2: Intel 82573L controller; RJ-45 x2 connector
Expansion Slots	PCIe x16 4.0 GB/s per direction-1 slot; PCIe x1 1 GB/s per direction-2 slot; PCI 32-bit/33 MHz-4 slots
FSB	800/1066/1333 MHz
Graphics	Embedded Intel GMA 3100 sharing 256 MB system memory; PCIe x16 slot Add-on
I/O Interface	1x VGA; 12x USB (2.0 compliant) 6 ports on board and 4 ports on rear I/O; 2x Audio (Mic-In, Line-Out); 4x Serial (3 of RS-232, 1 of RS-232/422/485); 1x Parallel (SPP/EPP/ECP), 1x FDD, 1x PS/2
Memory	Dual channel DDR2 667/800 MHz technology; 8GB Max capacity; 240-pin DIMM x 4 socket
Power Requirement	Typical-Intel Core 2 Quad9300 2.5 Ghz (1333 MHz FSB), 4 x 1 GB DDR2 800 SDRAM; +5V(3.58A); +3.3V(2.86A); +12V(3.52A); +5Vsb(0.74A); -12V(0.02A)
Processor	Intel Pentium Dual Core
Processor System	Core 2 Quad(2.83GHz, 12MB L2 cache); Core 2 Duo(3.16GHz, 6MB L2); Pentium Dual Core (2.2GHz, 1MB L2) Celeron (2.0GHz, 512KB L2)
SATA II	300 MB/s Max Data Transfer Rate; 6 Channel
Watchdog Timer	System reset output; programmable 1~ 255 sec./min. interval

Вес	1 кг
