Channels 32 | Output Type Sink (NPN) |
Isolation Protection | 2,500 VDC |
Output Voltage | 5 ~ 40 VDC |
Sink Current | 200 mA max. per channel |
Opto-Isolator Response | 100 μ |
Bus Type | ISA |
I/O Connectors | 37-pin D-type female |
Dimensions (L x H) | 185 x 100 mm (7.3” x 3.9”) |
Power Consumption | Typical: 5 V @ 330 mA; 12 V @ 80 mA Max.: 5 V @ 500 mA; 12 V @ 105 mA |
Operating Temperature | 0 ~ 60°C (32 ~ 140°F) |
Storage Temperature | -20~70°C(-4~158°F) |
Storage Humidity | 5 ~ 95% RH, non-condensing (refer to IEC 68-2-3) |
