アドバンテック FSP350-50FCB 電源

FEATURES
• Certified CB 62368-1 & CB 60950-1
• Meet 80 Plus Gold Level
• Design for 5,000 Meter above sea level
• High Reliability
• Low Ripple & Noise
• Over Current/Temp./Voltage Protection
• 100% Hi-pot tested
• 100% burn-in under high ambient temperature (50°C)

DESCRIPTION
FSP350-50FCB is a standard Flex form factor switching power supply. The power supply comes to offer the total power capacity up to
350 Watts, which makes it to be ideally used in an industrial environment. In addition, the power supply is ideally the best choice for IPC
controller, networking, communication or any other automation applications to use. The product also complies with the latest safety and
EMC standards, which is perfectly to meet various regulations worldwide.
GENERAL SPECIFICATIONS
Dimension (L x W x H): 81.5 x 40.50 x 150 (mm) Environment
Working temperature: 0°C to 50°C
Storage temperature: -40°C to + 80°C
Efficiency: 80 Plus Gold Working humidity: 85% RH non-condensing
Storage humidity: 95% RH non-condensing
Hold-up time at 100% 115V / 60Hz: ≥ 10ms
Loading: 230V / 50Hz: ≥ 12ms MTBF: 100,000 hours of continuous operation at 25°C, Max,-output load
Operating altitude: 5,000 meters above sea level Applications: Networking ,Storage System ,IPC Controller
