Specifiche
Add-on Module
| Series | Analog E(Intelligent) |
|---|---|
| Bus Specification | PCI |
| Misurare | Short Size |
| Used Connector | D-SUB 37-pin (Female); 2x Pin header 16-pin (Male) |
Analog I/O
| Input Channels | Single-ended 16-ch (Differential 8-ch) |
|---|---|
| Input Range | ±10V; ±5V; 0 to 10V; 0 to 5V |
| ADC Resolution | 16-bit |
| Sampling Rate | 1μsec/ch (max.) |
| Input Buffer Memory | 16M Word |
| Output Channels | 1-ch |
| Output Range | ±10V; 0 to 10V |
| DAC Resolution | 16-bit |
| Update rate | 10μsec (max.) |
| Output Buffer Memory | – |
Digital I/O
| Input Channels | 4-ch |
|---|---|
| Output Channels | 4-ch |
| Bi-directional I/O Channels | – |
| Response Time (Input) | 200nsec (max.) |
| Response Time (Output) | 200nsec (max.) |
| Operating Voltage (Input) | 5VDC-TTL |
| Operating Voltage (Output) | 5VDC-TTL |
| Input Circuit | Non-isolated TTL level input (Positive logic) |
| Output Circuit | Non-isolated TTL level output (Positive logic) |
| Built-in Power Supply | – |
